summary
kyn28-ii-armored removed three-phase ac 50hz ac metal-enclosed switchgear, and rated voltages up to 12kv. as power plants, substations and industrial and mining enterprises to accept and distribute electric energy, control the circuit, protective case detection, can also be used to control the frequent operation of site
structure description
kyn28-ii-armored removed three-phase ac 50hz ac metal-enclosed switchgear, and rated voltages up to 12kv. as power plants, substations and industrial and mining enterprises to accept and distribute electric energy, control the circuit, protective case detection, can also be used to control the frequent operation of site
structure description
switch cabinet armored gb3906 and iec298 type metal closed switch standard and overall design, the cabinet and the withdrawable part (cart) is composed of two parts, the body structure adopts aluminum steel or galvanized plate riveted combined molding, metal plate of the switch cabinet part for the circuit breaker room, the main bus chamber, a cable chamber and the relay control room, and all the metal structure reliability of grounding pressure are independent of each compartment of the main circuit system release channel.
main features
1, simple and effective "five-prevention" locking to prevent misuse;
2 can be used for pt handcart, handcart, isolation of measurement used, stand ground breaker, breaker is interchangeable for the same purposes;
3, enclosure wall installation, before the maintenance, reduce the floor area;
4, switchgear casing protection degree up to ip4x, protection provided by each compartment is ip2x; 5, the appearance of new, neat, concise, uniform colors, thick proportions;
6, the secondary lines of high-voltage indoor all-metal protective tank, running safe and reliable.
four, cabinet dimensions
height x width x depth：
2320mm 650mm 1500mm/1660mm/1800mm
800mm 1500mm/1660mm/1800mm
1000mm 1500mm/1660mm/1800mm
