summary
xgn15-12 (sf6) ac metal-enclosed ring network switching equipment which cabinet aluminum zinc coated steel panels assembled after cnc machining, protection grade ip3x, and has reliable mechanical interlock to prevent misuse and function.
main feature
1, the load switch is a separate unit inside is filled with sulfur hexafluoride gas as an insulating medium, long life, high-parameter, non-polluting, low-maintenance;
2, housing made of high quality aluminum-zinc plate, resistant to corrosion, oxidation, shape the new structure, and aesthetic advantages.
3, the spring charging operation, automatic three-phase trip, five anti-interlock with one operating mechanism, the linkage is safe and reliable;
4, rmu can easily form a ring network power supply unit and other wiring, and can be infinitely extended;
5, the use of sulfur hexafluoride load switch, safe and reliable overall performance, oil-free, non-toxic, do not fire and explosion hazard;
6, can be designed with kyn28-12 (gzs1) in the home cabinet and cabinet use.
structure size
deep x width x height (mm) 420x840x1600 (1800) 500x840x1600 (1800)
750x840x1600 (1800) 375x940x1650 (1850)
375x940x1650 (1850) 375x940x1650 (1850)
