summary
svac0n 8pt is a siemens the latest design of new low voltage switchgear. the complete type test, products comply with (387251.1-2005 and ec60439 1 and other relevant standards, can be widely used in the electronics industry, industrial and mining enterprises, tobacco industry, municipal facilities, commercial buildings, high-end residential areas.
main features
skeleton and outer skin
1 mounting holes on the frame are used as the modulus of 25mm, and there are many kinds of combination schemes.
2 kinds of flexible door, can satisfy different requirements
the maximum opening angle of the 3 door can be up to 180°
4 spring door lock can reliably prevent the door from accidental opening.
5 the top of the cabinet body with a pressure relief device
horizontal busbar system
1, the top of the standardized design of the main bus bar is located in the cabinet
2, the maximum rated current of main busbar can be up to 7400 a
3, according to the customer's requirements of the rated current rating
4, rated peak withstand current (ipk) can be up to 375ka
5, the main bus compartment and the compartment isolation device
6, from the above can be convenient for the connection of the bus between the transport units
frame circuit breaker scheme
1, using 3wt or 3wl circuit breaker
2, a maximum of 3 circuit breakers can be installed in each case
3, the outlet circuit breaker is 3 pole or 4 pole
4, the circuit breaker can choose fixed or draw out type
5, close the door, with the test and separation location
6, short circuit strength ipk to 375ka, icw to 150ka, 1s, to 100ka, 3s
installation method
can be divided into fixed installation technology, plug-in technology, plug-in technology, drawing technology before the opening of the line, draw out the technology after the opening of the connection
dimensions
high：2200，2600mm
width：400，600，800，1000，1200，1600 mm
depth：600，800，1000，1200 mm
protection level: ip30~lp54
